Manley I-Beam Rods Now Available at EdgeAutosport

[EdgeAutosport.com]

Just wanted to let you guys know that we now carry the line of Manley Turbo Tuff Pro Series I-Beam Rods



The Pro Series I-Beam rods are forged from 4340 aircraft quality vacuum degassed material. They are shot peened after machining and 100% magnafluxed. All Manley Connecting Rods are weight matched to +/- 1.5 grams and big and small end bores are final honed to a tolerance of +/- .0002".



You have a choice between 22 and 22.5 (stock) mm wrist pins as well as ARP 2000 and ARP 625+ rod bolts.



Manley Turbo Tuff Pro Series I-Beam Rods w/ ARP 625+ - $972.60
Manley Turbo Tuff Pro Series I-Beam Rods w/ ARP 2000 - $810

[LumberJack]

Them are some sexy rods

[Lex]

So what is the difference between the I beam and H beam "economical" rods they sell?

[LumberJack]

Originally Posted by Lex So what is the difference between the I beam and H beam "economical" rods they sell?

@Lex; this might help. It is just a general "hypothetical" comparison, but helped me a lot.



Sent from my LG-LS980 using Tapatalk

[Lex]

Most companies sell the h beam as the stronger rod and without actual dimensions we can't infer this. The description on the site labels the h beam as economical without giving any specs.

[EdgeAutosport.com]

I believe it has to do with how and where the rods are made. I believe the I-beams are made in America while the H-beams are farmed out to somewhere else. They are likely made along side K1 and eagle rods.

[BigRedSpecial]

Doesn't Carrillo offer an I beam as a stronger alternative to their H beam?

[LumberJack]

Originally Posted by BigRedSpecial Doesn't Carrillo offer an I beam as a stronger alternative to their H beam?

Never seen there I beams. But they make an extremely sexy A beam rod

Sent from my LG-LS980 using Tapatalk

[LumberJack]

Well, I tried calling Manley to get a better explanation on this and I referred him to that picture I posted since he had actually seen that comparison online on the corvette forums where I found it. He said it is a very good example and the representation of difference in design and showing how strength is actually different between the 2

[BigRedSpecial]

You're right, I was thinking of the A beams.

[Lex]

Carrillo makes a lower power rating A beam. These rods are also A beams as they flare out near the big end.

[EdgeAutosport.com]

Originally Posted by Lex Carrillo makes a lower power rating A beam. These rods are also A beams as they flare out near the big end.

I've always thought they were more like A-Beams, but Manley calls them I-Beams so thats what we sell them as.

[LumberJack]

Originally Posted by EdgeAutosport.com I've always thought they were more like A-Beams, but Manley calls them I-Beams so thats what we sell them as.

Yeah, I agree. Every company sells them differently there is no "industry" standard name for rods. The turbo Tuffs are I beam, they look like the Carillo A beams. Then the Manley I beams are there highest rated rods, and Carillo rates there H beams higher than there A beams.

[hnda etr]

@Hammology;
